SPEC 46205 AL Compact 5/8kV NLEPR Insulation 133/100% IL PVC Jacket. MV 105 - Tray Rated - Sunlight Resistant - For Direct Burial

350-35 3/C 3E AL 115 MILS NL-EPR 5KV 133%/8KV 100% T/S 1X3 CU GW BLACK P VC UL 617100015GS QC03 FLRBLGN

Southwire #: 58093299

Type MV-105 Three Conductor Aluminum, 115 Mils No Lead Ethylene Propylene Rubber (NL-EPR) 133% Insulation Level, Tape Shield, Polyvinyl Chloride (PVC) Jacket, Dual Rated UL/CSA

Download Category Specifications

PDF Excel Table

Select Product Specifications

Construction

Outer Jacket / Armor Color

Conductor Color

Packaging

Application

Southwire’s 5KV cables are suited for use in wet and dry areas, conduits, ducts, troughs, trays, direct burial, and where superior electrical properties are desired. These cables are capable of operating continuously at the conductor temperature not in excess of 105°C for normal operation, 140°C for emergency overload, and 250°C for short circuit conditions. Rated at -35°C for cold bend. For uses in Class I and II, Division 2 hazardous locations per NEC Article 501 and 502.Rated for 1000 lbs./FT maximum sidewall pressure.

Specifications

Stock #	58093299 58093299
No. of Conductors	3 3
Size (AWG or kcmil) (mm2)	350 KCMIL 350 KCMIL
No. of Strands	35 35
Insulation Thickness (mils) (mm)	115 2.92	mils mm
Size (AWG)	3 3
Nom. OD (mils) (mm)	2334 59.30	mils mm
Nominal Total Weight (lbs/1000') (kgs/km)	2808 4179	lbs/1000' kgs/km

Standards & References

ASTM B801: Concentric-Lay-Stranded Conductors of 8000 Series Aluminum Alloy
ASTM B836: Compact Rounded Stranded Aluminum Conductors
UL 1072: Medium-Voltage Power Cables
UL 1685: Vertical-Tray Fire Propagation and Smoke Release Test
UL 2225: Cables and Cable-Fittings For Use In Hazardous (Classified) Locations
CSA C22.2 No.230: Tray Cables - Rated TC-ER
CSA C22.2 No. 2556 / UL 2556: Cable Test Methods
CSA C68.10: Shielded Power Cables for Commercial and Industrial Applications - 5 to 46 KV
ICEA S-93-639: (NEMA WC 74) 5-46 KV Shielded Power Cable
ICEA S-97-682: Standard for Shielded Utility Cable Rated for 5 - 46kV
AEIC CS-8: Specification for extruded dielectric shielded power cables rated for 5 through 46KV (Qualification Test Requirements)
Made in America:: Compliant with both Buy American and Buy America Act (BAA) requirements per 49 U.S.C. § 5323(j) and the Federal Transit Administration Buy America requirements per 49 C.F.R. part 661

Construction

Conductor: Class B compact stranded 8000 Series aluminum per ASTM B800 and ASTM B836
Conductor Shield: Semi-conducting cross-linked copolymer; A conductor separator is used for cable size larger than or equal to 500 Kcmil
Insulation: 115 Mils No Lead Ethylene Propylene Rubber (NL-EPR) 133% Insulation Level,
Insulation Shield: Strippable semi-conducting cross-linked copolymer
Copper Tape Shield: Helically wrapped 5 mil copper tape with 25% overlap
Grounding Conductor: Class B compressed stranded bare copper ground per ASTM B3 and ASTM B8
Filler: Wax paper filler
Binder: Poly glass tape
Overall Jacket: Polyvinyl Chloride (PVC)
