Home Theater Sound Cable, Riser
Genesis Home Theater Sound Cables deliver dependable performance and unparalleled value.
Application & Features
Genesis® Riser Rated Home Theater Sound Cable is suitable for installation as follows:
- Installed in a metal raceway that complies with 300.22(B).
- Supported by solid bottom metal cable trays with solid metal covers.
- In risers.
- Within buildings in other than air-handling spaces and risers.
- Exposed to sunlight.
Specifications
Select a set of products below for more information:
| Conductors | |||||
| Size (AWG or kcmil) (mm2) | No. of Conductors | Stranding | Shielding | Nominal Total Weight (lbs/1000') (kgs/km) | |
| More Options |
16 AWG
16 AWG
|
2
2
|
Stranded
Stranded
|
Unshielded
Unshielded
|
23
34
|
| More Options |
14 AWG
14 AWG
|
2
2
|
Stranded
Stranded
|
Unshielded
Unshielded
|
34
51
|
| More Options |
14 AWG
14 AWG
|
4
4
|
Stranded
Stranded
|
Unshielded
Unshielded
|
64
96
|
| More Options |
12 AWG
12 AWG
|
2
2
|
Stranded
Stranded
|
Unshielded
Unshielded
|
52
78
|
| More Options |
16 AWG
16 AWG
|
4
4
|
Stranded
Stranded
|
Unshielded
Unshielded
|
43
65
|
Standards & References
Genesis® Riser Rated Home Theater Sound Cable meets or exceeds the following:
- UL 1666 - Riser Rated
- CSA C22.2 No. 2556 - FT4 Rated
- UL 444 - Communication Cables, Type CMR
- UL 1424 - Cables for Power-Limited Fire-Alarm Circuits, Type FPLR
- UL 13 - Power-Limited Circuit Cables, Type CL3R
- Sunlight Resistant Rated
- REACH/RoHS Compliant
Construction
Genesis® Riser Rated Home Theater Sound Cable features the following quality and convenience characteristics:
- Bare Copper conductors for excellent conductivity and low voltage drop.
- Polypropylene insulation.
- PVC jacket.
- Durable rip cord for efficient jacket stripping and removal.
- Countdown® Length Markings for easy tracking of usage and remaining cable.
- Rated for 300 Volts
- Rated for -20 °C to 60 °C.
